eMagTech 10PCS Mini RS232 MAX3232 to TTL Level Converter Serial Module Board Adapter 3~5V MAX3232 Breakout Board Computer Cable Serial Adapters Electronic Components
£11.45
In stock
Unlock seamless communication between your hardware projects and legacy serial devices with the eMagTech 10-Piece Mini RS232 to TTL Level Converter Set. This high-performance breakout board utilizes the industry-standard MAX3232 chip to provide stable bidirectional data transmission for microcontrollers, embedded systems, and computer peripherals. Its ultra-compact footprint and wide 3V to 5V operating range ensure universal compatibility and easy integration into space-constrained electronic designs.
- High-Efficiency MAX3232 Chip: Delivers ultra-stable bidirectional signal conversion between standard RS232 voltage levels and TTL logic for reliable data flow.
- Wide 3V-5V Compatibility: Offers universal support for modern development boards, including Raspberry Pi and Arduino, across both 3.3V and 5V systems.
- Bulk 10-Piece Value Pack: Provides a cost-effective solution for large-scale deployments, educational kits, or multiple prototyping projects.
- Ultra-Compact Breakout Design: Engineered for effortless integration into tight PCB layouts and small project enclosures without sacrificing performance.
In stock
Shipping & Delivery
-
Courier delivery under £30
Our courier will deliver to the specified address
2-3 Days
From £4.99
-
Prime delivery
Our prime courier will deliver to the specified address
1-2 Days
From £12.99
-
Manufacture Warranty 1 Year
-
Free 30-Day returns
Product Description
Product Overview
Unlock seamless communication between your hardware projects and legacy serial devices with the eMagTech 10-Piece Mini RS232 to TTL Level Converter Set. This high-performance breakout board is the ultimate solution for engineers and hobbyists needing to bridge the gap between RS232 voltage levels and TTL logic. Powered by the industry-standard MAX3232 chip, these modules ensure ultra-stable data transmission for programming microcontrollers, debugging embedded systems, or interfacing with personalized computer peripherals. Its ultra-compact footprint makes it an ideal choice for space-constrained electronics projects, while the wide 3V to 5V operating range provides universal compatibility with both 3.3V and 5V systems. Whether you are a professional developer or a DIY enthusiast, this bulk pack offers the reliability and versatility required to keep your serial-based projects running at peak efficiency.
Key Features
- High-Efficiency MAX3232 Chip: Delivers reliable bidirectional signal conversion between standard RS232 and TTL logic levels.
- Bulk 10-Piece Value Pack: Ensures you always have a high-quality serial adapter on hand for multiple prototypes or large-scale deployments.
- Ultra-Compact Design: Designed for maximum portability and effortless integration into tight PCB layouts or small project enclosures.
- Wide Voltage Compatibility: Operates flawlessly within a 3V to 5V range, making it compatible with Raspberry Pi, Arduino, and other modern microcontrollers.
- Intelligent Signal Flow: Features clear directional arrows to indicate signal input and output, simplifying the wiring process for beginners and pros alike.
- Dual Independent Channels: Equipped with two independent channels for TXD and RXD, allowing for full-duplex communication.
Important Information
- Input Voltage: Supports a DC power supply range of 3.0V to 5.5V.
- Baud Rate Performance: Optimized for stable performance at speeds up to 120kbps.
- Wiring Tip: Power supplies on both sides are connected internally; you only need to connect power to one side to activate the entire module.
- Package Contents: Includes 10 individual Mini RS232 to TTL Level Converter boards.
Why Choose Think Assemble
- Quality Assurance: We source only high-grade electronic components that undergo rigorous testing to ensure long-term durability and performance.
- Expert Technical Support: Our team of specialists is ready to assist you with integration questions or troubleshooting for your serial projects.
- Fast & Secure Shipping: We prioritize efficient logistics to ensure your essential components arrive safely and on schedule.
- Comprehensive Inventory: Think Assemble is your one-stop shop for reliable breakout boards and adapters, helping you streamline your development process.
Specification
Overview
| Weight | 10 g |
|---|---|
| Dimensions | 13.1 × 11.3 × 0.9 cm |
| Item model number | EC1_EMT_58 |
| Package dimensions | 13.1 x 11.3 x 0.9 cm; 10 g |
| ASIN | B0B1D63X4V |
| Guaranteed software updates until | unknown |
| Manufacturer | eMagTech |
