Voltage and Current Output USB Device, 8 Channel, 16 bit, 100S-

Product Overview

USB-3104 is a voltage and current output USB device. It features eight voltage/current output channels, eight digital I/O, and one counter input. Each channel is software-selectable for either a bipolar voltage output range of ±10 V or a unipolar range of 0 V to 10 V. Channel outputs can be updated individually or simultaneously. USB-3102 also features 0 mA to 20 mA of current output. Each DAC controls a voltage/current channel pair simultaneously. Each channel pair can be updated individually or simultaneously. Software support includes DAQami, an out-of-the-box application for data logging, visualization, and signal generation. Data can be viewed in real-time or post-acquisition on user-configurable displays. Drivers are included for the most popular applications and programming languages including Visual C++, Visual C#, Visual Basic.NET, DASYLab, LabVIEW , MATLAB, Linux, and Python .

– USB 2.0 full-speed, high-drive device
– Quad (4-channel) 16-bit digital-to-analogue converter (DAC)
– Eight bidirectional digital I/O connections
– 32bit counter can count TTL pulses
– Powered by the +5V USB supply

Contents

USB-3104, USB cable, Printed insert: DAQami quick start, MCC packaging assembly/foam.

Footnotes
In addition, we have calibration services for this product (Europe only). Visit our calibration service page to see details of what options are available.
