Varme Programmable Underfloor Heating Thermostat – Model FH-01

User Manual

The Varme FH-01 Programmable Underfloor Heating Thermostat has been designed specifically with electric underfloor heating in mind.

The thermostat is energy efficient, reliable and provides full programming control. It can handle a 16 Amp load, yet is incredibly easy to use with a full 7 day, 24 hour timer.

The FH-01 features 3 different functions:

– Floor sensor only: Ideal for when you only want to control the floor surface temperature. For example, conservatories
– Air & Floor: The thermostat controls the air temperature whilst using the floor sensor to prevent overheating of the floor system
– Remote Air & Floor: Ideal for remote control of the air and floor temperature. For example, bathrooms

Probe Installation:

It is recommended for the probe to be installed into a conduit so that it can be easily retrieved if required.

To purchase the Varme underfloor heating system, please click here.

Features:

– Floor sensor is included
– Weekday/weekendor 7 day programming options (selectable in software)
– Temperature hold feature
– Day and night temperature feature
– Holiday temperature selection feature
– °C / °F Selectable
– Self learning optimum start on 1st and 3rd level
– Keylock facility
– Frost protection with adjustable temperature setting
– Remote control option (RM1)
– 16A switch rating
– Blue backlight (turns on after 30 seconds)
– Wattage: 3,680W
– Voltage: 230V AC
– Weight: 0.2kg
– Dimensions: H 9.8 x W 8.5 x D 1.3 cm
