Two Output IP and Ethernet Mains Switch-

Product Overview

The IPMSW1 PLUS is an IP controllable mains power switch with two independent mains outputs. Both outputs can be monitored and controlled over the internet via any web broswer or smartphone. Simple configuration with comprehensive switching options as well as support for IFTTT commands and voice control using an Alexa device.

– Switch up to 10A (total combined output)
– Manual override button for each switch
– Simple & intuitive browser based set-up and configuration
– 3 Timer events per switch with daily/weekly/monthly repeat function
– Add an optional hard wired control switch via the front jack socket
– Automatically power cycle each output on ping fail
– Integrated Real Time Clock IC with 5 year battery backup
– Ethernet or WiFi connectivity
– Switch has its own IP address, and can be controlled using port forwarding
– Supports DDNS and can be controlled via IFTTT or Amazon Echo commands
– Dimensions (HxWxD): 48x185x136mm

Contents

Switch, IEC female to UK mains plug lead, IEC male to UK mains socket lead, IEC male to female lead
